We are manufacturer, supplier of Tumblast type Shot Blasting Machine. Our Setup Situated in Aurangabad, Maharashtra, India.

Tumblast Type Shot Blasting Machine
Model Tum 2736
Capacity 5 Cub. Fee
Tumblast Type Shot Blasting Machine
Model Tum 2027
Capacity 2 Cub. Feet.
Tumblast Type Shot Blasting Machine
Tumblast Type Shot Blasting Machine

We offer tumblast type shot impacting machines.

Applications :

  • Cleaning of projecting and fashioning.
  • Expulsion of intensity therapy scales.
  • Setting up the surface before electro-plating, electrifying, metallising.
  • Plating, rubber treating, bakelite, covering and so on
  • Cleaning for re-molding.
  • Plastic de-blazing.
  • Shot peening of springs, gears, and so forth to increment weariness life.
  • Carving for oil holding properties to supplant corrosive pickling.
  • Numerous different applications for little parts.
  • Cleaning of casting and forging.
  • Removal of heat treatment scales.
  • Automobile components
  • Preparing the surface prior to electro-plating, Galvanizing, Metallising.
  • Enameling, Rubberizing, Bakelite, Coating etc.
  • Cleaning for re-conditioning.
  • Plastic de-flashing.
  • Etching for oil retaining properties to replace acid pickling.
  • Many other applications for small components.

Conveyor Flights : Close fitting and reinforced for durability.

Conveyor Links : Tough one piece, Case hardened and stress relieved steel castings.

Traction Wheels And Sprockets : Fabricated from Steel Plates.

Barrel Heads : Adjustable to keep mill tight protected with wear plates.

Door : Lined with wear plates, Travels in completely inter locking seal.

Separators : Compensating abrasive flow provides high efficiency separation with minimum adjustment.

Tumblast Models : Also available in both rubber and slat conveyor type

Technical Data

  a   a

   RUBBER BELT

   SLAT CONVEYOR

   MODEL

   20 X 27

   27 X 36

   27 X 36

   CAPACITY

   2 CU FT

   5 CU FT

   5 CU FT

   NO OF TURBINES

   1 NO

   1 NO

   1 NO

   TURBINE SIZE

   300 X 63

   380 X 63

   380 X 63

   TURBINE DRIVE

   5 H P

10 H.P.

   15 H.P.

   TOTAL H.P.

   13 H.P.

   18 H.P.

   25 H.P.

Plant Dimensions In MM

   L

   1100

   1400

   W1

   610

   1050

   W2

   865

   1225

   H1

   1650

   2015

   H2

   1750

   2015

   H

   3750

   4100

   S

   600

   --
